Detailed Product Description
Basic Info
| Model No.: KYT | Tile Type: Colored Steel |
| Certification: SGS, CE, ISO, Other | Condition: New |
| Customized: Customized | Usage: Other |
| Transmission Method: Machinery | Name: Galvanized Window Frame Roll Forming Machine |
| Control System: PLC | Cutting Type: Hydraulic Cutting |
| Certificate: ISO9001/CE | Material Of Cutting Blade: Cr12 Heat Treatment |
| Place Of Origin: China(Mainland) | Warranty: 18 Months |
| Aftersale Service: Engineer Can Maintain Machine Overboard | Packing: By Water Proof Paper |
| Deliever: Within 45 Days | |
Additional Info
| Packaging: seaworthy packing | Productivity: 30 sets per month |
| Brand: KAIYITE | Transportation: Ocean,Land |
| Place of Origin: China | Supply Ability: 30 sets per month |
| Certificate: ISO9000/CE | HS Code: 8455221000 |
| Port: Tianjin Port | |
Product Description
Roll Forming Machine For Door Frame
The roll forming machine for door frame is different from the common Steel Door Frame Roll Forming Machine . It needs the punching system to make the hole and small bar . So the finished profiles can bite each other by these holes and bars ,
and no need to weld . In this way, it can save labour cost and improve the working efficiency . Also the profile is more accurate than the welded door frame .
The flow chart of the metal door frame forming machine
Finished Product of Galvanized Window Frame Roll Forming Machine
Steel Door Frame Roll Forming Machine Parameter
Below is some details of the door frame machines:
(Machine pictures are for your reference)
1.: 3 Ton hydraulic Decoiler
This part is composed by the following elements: 3 Ton Hydraulic decoiler
3 Ton Hydraulic decoiler:
Loading ability: 3T Max coil width:400mm
Inner diameter:450-508mm outer diameter: Max 1500mm
2.: roll forming machine
1.Feature Ensure the stability, accuracy and long life
2.Main forming machine Size 8500mm*1200mm*1500m(L*W*H)
3.Main forming machine weight 7.5Ton
4.Voltage 380V 50Hz 3 Phrase (380 V is China normal voltage, but the voltage can be customize by customer.)
5.Method for fixing roller Memorial arch frame
6.Material of shafts 45# steel Thermal refining
7.Transmission method Gear
8.The main shaft material No. 45 steel quenching and tempering treatment
9.Outer shaft diameter 60mm
10.Wheel material Quenching process of GCr15 bearing steel HRC58-60
11.Roller16 stations
12.The main motor power: 7.5kw
3. hydraulic station
1.Hydraulic oil 46#
2.Hydraulic power 4kw
3.Components The system includes a set of hydraulic tank ,
a set of hydraulic oil pump, two hydraulic pipes.
and two sets of electromagnetism valves
4. PLC Control Device
1.Control By PLC
2.PLC language As required
3.Touch screen Delta
4.Function Automatic length and quantity measurement
5.Include Equipped with movable switch , air break,
radiator, transformer & electric leakage protector for
6.operation convenience and safety.
7.Feature Adopted PLC , transducer, touch panel from
Mitsubishi Japan to ensure high speed with stability,
precision and lifetime.
More Picture of the About Galvanized Steel Door Frame Machine
