Detailed Product Description
Basic Info
| Model No.: KYT | Tile Type: Colored Steel |
| Certification: SGS, CE, ISO | Condition: New |
| Customized: Customized | Usage: Roof, Wall, Other |
| Transmission Method: Machinery | Place Of Origin: China |
| After-sales Service Provided: Engineers Available
To Debug The Machine Overseas |
Delivery Time: Within 45 Days |
| Warranty: 18 Months | RAW MATERIAL: Colored Steel Sheet,
galvanized Steel Sheet |
| Control System: PLC | Cutting Type: Hydraulic Cutting |
| Production Capacity: 8-15meter/min | Certificate: CE/ISO9001 |
| Name: Australia Type Roller Shutter Security Door Machine | |
Additional Info
| Packaging: Seaworthy packing | Productivity: 30 sets per month |
| Brand: KAIYITE | Transportation: Ocean,Land,Air |
| Place of Origin: China | Supply Ability: 30 sets per month |
| Certificate: ISO9001/CE | HS Code: 84552210 |
| Port: Tianjin Port,Shanghai Port | |
Product Description
Australian Style Rolling Shutter Door Roll Forming Machine
Australian Style Rolling Shutter Door Roll Forming Machinical models include:250 , 760,800,830,and 850. The 800 and 830 models have been favored by customers and have been selling well. For many years, our company has been committed to the continuous development and renewal of rolling door machinery and rolling door machine, ensuring to provide customers with high-quality rolling door machine.
Working Flow Of Australia Shutter Door Roll Foming Machine
5 Tons Decoiler — Panel Feeding And Guiding Table — Main Roll Forming Machine — PLC Control System — Hydraulic Cutting Device — Product Receiving Table
Quick Technical Parameters
* Voltage : 380V 50Hz 3Phases * Productivity : 8-12m/min
* Material of rollers : 45#steel * Roller Stations : 18 Stations ( Accroding to the drawing )
* Material Of Shaft : 45#steel * Diameter Of Shaft : Ф70mm
* Main Power : 3Kw * Hydraulic Power : 3Kw
* Cutting Type : Hydraulic Cutting * Material Of Blade : Cr12
* Main Body : 350 H Steel * Thickness Of Middle Plate : 16mm
* Driving Type : By Chain * Thickness Of Raw Material : 0.3-1.0mm
Finished Product
Machine Feature
* Low Cost * High efficiency * 18 Months Warranty
* Reliable working * Low energy consumption * Easy to operate
* Long working life * Accurate * Full automatic
* No noise
6m Seaming Machine
This machine used to combin two pieces of shutter door strip together well .
Some Common Profile Of Australia Shutter Door
Application
Australia Type Roller Shutter Security Door is widly used in shop , garage , workshop and so on . It play a more and more important role in the house .
Clients Visit
Welcome customers all over the world to visit us .
Contact Us
If you want to know more about this machine, please contact us freely.
Looking for ideal Australian Style Roll Forming Machine Manufacturer & supplier ? We have a wide selection at great prices to help you get creative. All the Roll Down Shutter Door are quality guaranteed. We are China Origin Factory of Roll Forming Machine Of Shutter Door. If you have any question, please feel free to contact us.
