Detailed Product Description
Basic Info
Model No.: KYT | Tile Type: Colored Steel |
Certification: SGS, CE, ISO | Condition: New |
Customized: Customized | Usage: Roof, Wall, Floor |
Transmission Method: Hydraulic Pressure | Place Of Origin: China |
After-sales Service Provided: Engineers Available
To Debug The Machine Overseas |
Brand: KYT |
Warranty: 24 Months | RAW MATERIAL: Colored Steel Sheet,
galvanized Steel Sheet |
Control System: PLC | Cutting Type: Hydraulic |
Voltage: As Your Required | Production Capacity: 8-15meter/min |
Thickness Of Raw Material: 0.8-2mm |
Additional Info
Packaging: Seaworthy packing | Productivity: 30 sets per month |
Brand: KAIYITE | Transportation: Ocean |
Place of Origin: China | Supply Ability: 30 sets per month |
Certificate: ISO9000 | HS Code: 84552210 |
Port: Tianjin,Shanghai,Guangzhou |
Product Description
77 PU Foam Roller Shutter Door Forming Machinery
77 PU Foam Roller Shutter Door Roll Forming Machinery adopts the most advanced technology . The cutting system is automatic fly saw cutting with servo motor .The transmission system is Gear box with universal joint .
The base frame is more stable compared with the old Shutter Door Roll Forming Machine . And all the Brand of the PLC cotrol box is Delta .Main components for low pressure electricity: Schneider Germany . So that we can ensure that the roll forming machine has a long service life .
The advantage of the PU Rolling Shutter Slats Roll Forming Machine .
1. Energy saving and environmental protection
Each piece profile of the insulated shutter door is filled with environmentally friendly insulation materials , it can effectively maintain the indoor temperature , save a lot of energy . Energy-saving effect can reach 30%, is the ideal energy-saving environmentally friendly building materials.
2. Thermal insulation
The special material and unique structure make it effectively prevent strong lisght and ultraviolet radiation . The temperature of the blocking rate can reach more than 95% .
3. Noise Reduction
The PU foam shutter door roll forming machine has no noise when it runns . Also it can reduce the interference of external noise . Protect us live in you peaceful life .
The Hydraulic Metal Shutter Door Roll Forming Machines component:
1.Decoiler 1 set
2.Guide Feeding device 1 set
3.main forming machine 1 set
4.PU Foaming machine 1 set
5.Straighten device 1 set
6.flying saw Cutting Machine 1 set
7.finished products table 1 set
8.PLC control system 1 set
Here is the roll forming machine pictures for your reference:
The Main specification of the Roller Shutter Door Roll Forming Machine
1. material: aluminm coil plate and colorful galvanized steel
2. material thickness: 0.27-0.4mm, coil width: 140mm
3. decoiler:3 ton manual
4. forming stations: 38 stations
5. roller material: GCr15
6. shaft diameter: 40mm
7. drive way: gearbox drive
8. frequency conversion decelerating: Delta
9. forming speed: 8-15m/min
10. machine size: 24000mmx600mmx900mm
11. machine weight: 7 tons
Clients may meet many problems when using the Galvanized Roller Shutter Door Equipment. We will give you a good solution to solve them and make you free of trouble .
Such as the following :
1. what space do we need for the roll forming machine
2. the distance of between the roll machine body and decoiler
3. How to install the steel coil with the manual decoiler
4. how to adjust the distance of the upper and down shaft
5. How to cut the steel coil when finish the working
6. How to set the numbers in control box
7. How to connect the wiring of roll forming machine
8. what kind of hydraulic oil should be filled in hydraulic motor box
9. How many oil should be filled in box
10. The machine not work automatically.
11. The cutter not goes up when cut the panel
12. the panel goes a wrong way in roll forming machine body, not form in one line
13. Client changed the parameter of encoder, i help them to change the parameter
14. the panel not stop when reach the length
15. Motor oil leakage
16. How to adjust the forming speed of roll forming machine
Kaiyite machinery is a leading manufacture of roll forming machine . We know well the particular requirements for the customers from different countries , and have an outstanding export team who will take your requests . Our experts and skilled workers complete the work with great precision .
We provide an extensive line of products , including shutter door machine , Door Frame Machine , roof and wall panel machine , Floor Deck Roll Forming Machine ,Stud And Track Roll Forming Machine
Purlin forming machine , tile roof machine , floor decking machine and other associated equipment .
If you want to know more information of the Door Frame Roll Forming Machine , please contact with berton .
